Vp260 Small Vacuum Pump Air Hand Vacuum Pump Machine Double Stage Vacuum Pump

Send Inquiry

Product Description

Standard Features
* * Aluminum alloy casing: Alloy casing has high heat dissipation to keep the motor and pump cool, while being light weight and efficient
* Two-Stage Rotary Vane Deep Vacuum Pump
* Direct drive motor allows for easy start up and is maintenance free
* Direct coupling between the motor and pump results in quiet running and good performance
* Force fed lubrication provides clean, filtered oil to all internal bearings and wearing surfaces regardless of the pump
operation. Cleaner oil reduces ware and break downs.
* Oil drain valve positioned at bottom of oil reservoir.
* Ballast valve on top of the pump
* Great tool for: system evacuation (refrigeration or air conditioning), printing, medical, vacuum packing, hot forming
plastics and other requirements where a high quality pump may be required

Vacuum pump VE245

* Nominal Capacity: 7.6 m3/h
* Final vacuum : <0,005 mbar
* Motor Power: 1/2 HP
* Voltage: 220 V 50 Hz
* Oil volume: 340 ml
* Length x width x height: 340x138x244 mm
* Net weight: 11.4kg
* Vacuum-Flange: 3/8"/25KF
* Article-Number 1 ph: Z13105

Vacuum pump VE215

* Nominal Capacity: 2.6 m3/h
* Final vacuum : <0,005 mbar
* Motor Power: 1/4 HP
* Voltage: 220 V 50 Hz
* Oil volume: 180 ml
* Length x width x height: 308x124x228 mm
* Net weight: 7.5 kg
* Vacuum-Flange: 3/8"/25KF
* Article-Number 1 ph: Z13104

Vacuum pump VE260

* Nominal Capacity: 10.2 m3/h
* Final vacuum : <0,005 mbar
* Motor Power: 3/4HP
* Voltage: 220 V 50 Hz
* Oil volume: 600 ml
* Length x width x height: 395x145x260 mm
* Net weight: 16.5 kg
* Vacuum-Flange: 3/8"/25KF
* Article-Number 1 ph: Z13106

For more models, please contact us！

item No.	VE135		VE135	VE145		VE145	VE160	VE160
Frequency	50Hz	60Hz	50Hz	60Hz	50Hz	60Hz
Flow rate	3.5CFM	4CFM	4.5CFM	5CFM	6CFM	7CFM
	100L/min	114L/min	128L/min	142L/min	170L/min	198L/min
Vacuum limit	5Pa		5Pa	5Pa		5Pa	5Pa	5Pa
Stage	1		1	1		1	1	1
Power	1/3HP			1/3HP			1/3HP

Raydafon Group specialist in making all kinds of mechanical transmission and hydraulic transmission like: planetary gearboxes, worm reducers, in-line helical gear speed reducers, parallel shaft helical gear reducers, helical bevel reducers, helical worm gear reducers, agricultural gearboxes, tractor gearboxes, auto gearboxes, pto shafts, special reducer & related gear components and other related products, sprockets, hydraulic system, vacuum pumps, fluid coupling, gear racks, chains, timing pulleys, udl speed variators, v pulleys, hydraulic cylinder, gear pumps, screw air compressors, shaft collars low backlash worm reducers and so on. furthermore, we can produce customized variators, geared motors, electric motors and other hydraulic products according to customers' drawings. We provides a reliable grantee for the product' s quality by advanced inspection and testing equipment. professional technical team, exquisite processing technology and strict control system. In recent years, the company has been developing rapidly by its rich experience in production, advanced management system, standardized management system, strong technical force. We always adhere the concept of survival by quality, and development by innovation in science and technology. Our Group is willing to work with you hand in hand and create brilliance together!
