Product Description

PTO Drive Shaft

1-3/8" 6-spline ends 49"-71" Series 4

This splined PTO shaft is built from sturdy steel and features 6-spline tractor and implement ends. It stands out by its adjustable telescoping tube, strong horsepower, and simple replacement. It can serve as farm power tools to improve your work efficiency significantly. Keep rolling through work, our drive shaft will make sure the job gets done.

Sturdy and Durable
6 Spline Ends
Adjustable Length
Easy Assembly Safer Use


Durable PTO Shaft This T4 tiller PTO shaft is built from high-quality 20CrMnTi carburized steel and Q345 tube steel, with a black-painted surface. It is durable enough to withstand large impacts, higher torque, and high speed.	Perfect Match With 49"-71" extendable length and featuring 1-3/8" 6-spline on both tractor and implement ends (include a slip clutch), the PTO link shaft perfectly fits powered farm equipment or machinery of the same size.	Powerful Transmission Force Our PTO shaft stands out with superior power-transfer ability. At 540 rpm it can provide 35 hp, 26 kw, and 460 nm torque; 53hp, 39kw, and 360 nm at 1000 rpm.


Structure Analysis The PTO shaft is assembled in a compact structure, consisting of a slip clutch, a telescoping tube, a universal joint, yokes, a plastic shield, and a chain for protection. It allows two speeds on both ends and transfers the power into the equipment.	Simple & Quick Installation The PTO shaft for the bush hug attaches to implement ends and tractors quickly. If you want to cut it to a proper length, please read the manual carefully and remember to deburr the edges after cutting.	Wide Application The PTO shaft, proving robust power force to the PTO powered attachment, is most commonly used on mowers, wood chippers, rotary tillers, rotary cutters, brush cutters, hush hug, tractors, etc.

1 x PTO Shaft with Slip Clutch
1 x Locking Pin
1 x User Manual

Specifications

Part Type: PTO Drive Shaft
Material: 20CrMnTi Carburized Steel + Q345 Steel + Plastic
Tractor End: 1-3/8" x 6 Spline
Implement End: 1-3/8" x 6 Spline
Compressed Length: 49" / 1250 mm
Extended Overall Length: 71" / 1800 mm
Max Torque: 900Nm
Friction Disc Dia.: 5.5" / 140 mm
At 540RPM: 35hp, 26Kw, 460Nm
At 1000PRM: 53hp, 39Kw, 360Nm


	PTO Drive Shaft 31.5"-41"	PTO Drive Shaft 43"-59", With Slip Clutch	PTO Drive Shaft 47-67"	T1 PTO Drive Shaft 27"-35"	PTO Drive Shaft 43"-61"	T4 PTO Drive Shaft 49"-71
Tractor End:	1-3/8" x 6 Spline	1-3/8" x 6 Spline	1-3/8" x 6 Spline	1-3/8" x 6 Spline	1-3/8" x 6 Spline	1-3/8" x 6 Spline
Implement End:	1-3/8" x 6 Spline	1-3/8" x 6 Spline	1-3/8" x 21 Spline	1-3/8" x 6 Spline	1-3/8" x Round End	1-3/8" x 6 Spline
Compressed Length:	31.5" / 800 mm	43" / 1100 mm	47" / 1200 mm	26.8" / 680 mm	43" / 1100mm	49" / 1250 mm
Extended Overall Length:	41" / 1050 mm	59" / 1500 mm	67" / 1700 mm	35.4" / 900 mm	61" / 1550mm	71" / 1800 mm
At 540RPM:	35hp, 26Kw, 460Nm	35hp, 26Kw, 460Nm	55hp, 40Kw, 850Nm	16hp, 12Kw, 210Nm	35hp, 26Kw, 460Nm	35hp, 26Kw, 460Nm
At 1000RPM:	53hp, 39Kw, 360Nm	53hp, 39Kw, 360Nm	83hp, 61Kw, 690Nm	24hp, 18Kw, 170Nm	53hp, 39Kw, 360Nm	53hp, 39Kw, 360Nm
